VEGA 1000 Online UPS systems are engineered using advanced power-conversion technology and high-reliability components to provide optimum protection for critical loads, while minimizing energy losses and ensuring zero interference with downstream equipment.
Designed for 1–3kVA single-phase input/single-phase output applications, the VEGA 1000 series adopts a true on-line double conversion (VFI) topology, integrating the latest three-level inverter architecture for exceptional efficiency and performance.
In operation, the connected load is continuously powered by the inverter, which delivers a pure sinewave output precisely regulated in both voltage and frequency. Advanced input and output EMI/RFI filters enhance protection, ensuring superior immunity to mains disturbances, voltage transients, and lightning-induced surges.
KEY FEATURES
- Latest three-level inverter architecture for superior performance and reduced switching losses
- High operational efficiency ensuring minimal energy consumption
- Pure sinewave output with precise voltage and frequency regulation
- Advanced digital control interface for real-time system monitoring
- Remote emergency power-off (EPO) capability for enhanced safety
- Microprocessor-based control for accurate and reliable system operation
- Integrated RS-232 and USB communication ports for easy connectivity
- Cold start functionality enabling operation directly from battery power
- Effective protection against voltage transients and spikes
- Built-in self-diagnostic routines for continuous system supervision
- Intelligent battery management system to maximize battery lifetime
- Comprehensive overload and short-circuit protection
- Excellent output voltage stability under all load conditions
APPLICATIONS
- Industrial & commercial power systems
- Data centers, server rooms, ICT infrastructure
- Medical, laboratory & precision instrumentation
- Manufacturing automation and control equipment
- Finance, banking, POS & transaction systems
- Network backbone, broadcast & telecom nodes
Choose our Single Phase UPS Series for maximum continuity and clean power performance.
CATALOG
TECHNICAL SPECIFICATIONS
