VEGA 2000 Series Online UPS systems are developed with the latest power conversion technologies and high-quality components to ensure maximum protection for critical loads, optimized energy efficiency, and zero interference with connected systems.
This range covers 10–40kVA single-phase input/single-phase output models based on on-line double conversion topology (VFI – Voltage and Frequency Independent) with three-level IGBT inverter architecture for superior efficiency and reliability.
The connected load is continuously powered by the inverter, which supplies a pure sinusoidal output voltage precisely filtered and stabilized in both amplitude and frequency. Advanced input and output filtering stages provide enhanced immunity against mains disturbances, surges, and lightning-induced transients.
In terms of performance and technology, the VEGA 2000 Series represents one of the most advanced UPS solutions in its class offering up to 95% efficiency at half load, unity power factor (1.0) output, and reduced system losses for improved overall energy utilization.
KEY FEATURES
- Three-level IGBT topology for reduced losses and lower operating temperature
- True on-line double-conversion (VFI-SS-111) isolation and protection
- Unity output power factor (1 kW = 1 kVA) for maximum usable capacity
- IGBT PWM rectifier & inverter with superior input/output waveform quality
- AC-AC efficiency up to 95 %, Eco-Mode up to 98 %
- Low input current THD (≤ 3 %) and input PF > 0.99 for grid compatibility
- Cold-start capability – inverter operation from battery without mains supply
- Smart battery charger extending battery lifetime by up to 35 %
- Temperature-compensated three-stage charging with flexible battery configuration
- Wide input-voltage window and load-dependent low-voltage tolerance (-36 %)
- Frequency-converter operation (50/60 Hz)
- Comprehensive protection: short-circuit, overload, surge, lightning
- Parallel operation up to 4 units for redundancy and capacity increase
- 256-event real-time log with full parameter tracking
- Built-in static & manual bypass for uninterrupted maintenance
- Compact footprint with intelligent fan-speed control for extended service life
- Advanced communication options: SNMP, RS-485/Modbus, RS-232, dry contacts
- Remote monitoring & management software
- Emergency Power Off (EPO) interface and generator soft-start compatibility
APPLICATIONS
- Industrial & commercial power systems
- Data centers, server rooms, ICT infrastructure
- Medical, laboratory & precision instrumentation
- Manufacturing automation and control equipment
- Finance, banking, POS & transaction systems
- Network backbone, broadcast & telecom nodes
Choose our Three Phase Input, Single Phase Output Online Double Conversion UPS Series for maximum continuity and clean power performance.
CATALOG
TECHNICAL SPECIFICATIONS
