VEGA 3000 Series is a high-performance Online UPS platform utilizing modern 3-Level IGBT power architecture, delivering superior power quality, maximum system availability, and highly optimized lifecycle operating cost.
The system delivers unity power factor (PF=1) both at input and output, while providing extremely low input harmonic distortion (THDi ≤3%), significantly reducing installation infrastructure requirements and improving overall power network quality.
With output PF=1, VEGA 3000 ensures ideal protection for advanced IT, data center, industrial automation and power sensitive electronics, delivering extremely low output THDv (≤2%) and supporting all load types (inductive, resistive, capacitive or mixed) without derating.
Efficiency performance is class-leading: up to 96% in On-line mode (half load) and 98% in Smart Eco-Mode, substantially reducing total energy consumption and HVAC cooling demand across the operational life cycle.
For full system scalability and lifecycle alignment, VEGA 3000 offers maximum configuration flexibility, parallel redundant expansion capability, and advanced communication interfaces. The compact mechanical platform provides low weight and reduced footprint for simplified installation in constrained environments.
KEY FEATURES
- Three-level IGBT topology for reduced losses and lower operating temperature
- True on-line double-conversion (VFI-SS-111) isolation and protection
- Unity output power factor (1 kW = 1 kVA) for maximum usable capacity
- IGBT PWM rectifier & inverter with superior input/output waveform quality
- AC-AC efficiency up to 95 %, Eco-Mode up to 98 %
- Low input current THD (≤ 3 %) and input PF > 0.99 for grid compatibility
- Cold-start capability – inverter operation from battery without mains supply
- Smart battery charger extending battery lifetime by up to 35 %
- Temperature-compensated three-stage charging with flexible battery configuration
- Wide input-voltage window and load-dependent low-voltage tolerance (-36 %)
- Frequency-converter operation (50/60 Hz)
- Comprehensive protection: short-circuit, overload, surge, lightning
- Parallel operation up to 8 units for redundancy and capacity increase
- 256-event real-time log with full parameter tracking
- Built-in static & manual bypass for uninterrupted maintenance
- Compact footprint with intelligent fan-speed control for extended service life
- Advanced communication options: SNMP, RS-485/Modbus, RS-232, dry contacts
- Remote monitoring & management software
- Emergency Power Off (EPO) interface and generator soft-start compatibility
APPLICATIONS
- Industrial & commercial power systems
- Data centers, server rooms, ICT infrastructure
- Medical, laboratory & precision instrumentation
- Manufacturing automation and control equipment
- Finance, banking, POS & transaction systems
- Network backbone, broadcast & telecom nodes
Choose our Three Phase Online Double Conversion UPS Series for maximum continuity and clean power performance.
CATALOG
TECHNICAL SPECIFICATIONS
