ORION 3000-STC Series Static Voltage Stabilizer is designed to protect sensitive equipment by stabilizing mains voltage and eliminating overvoltage, undervoltage, and network imbalances. With electronically controlled regulation, they ensure a consistent and reliable output voltage under fluctuating supply conditions.
When voltage levels exceed the adjustment range, the regulator automatically disconnects the output through an electromechanical mechanism, preventing potential damage to connected loads. This combination of fast electronic protection and secure disconnection provides dependable performance, extended equipment life, and uninterrupted operation for everyday applications.
KEY FEATURES
- Three phase input / Three phase output
- Static Automatic Voltage Regulator (AVR)
- Power range: 10–2000kVA
- Input voltage: 300–480 VAC (3P+N)
- Input frequency: 50 Hz
- Output voltage: 380 / 400 VAC (3P+N)
- Output voltage tolerance: ±2%
- Regulation speed: up to 5000 V/s
- Efficiency: >97%
- Operating temperature: 0°C to 40°C
- Relative humidity: 0–95% (non-condensing)
- Acoustic noise level: <55 dBA
- Short-term overload capability: up to 500% for 20 ms
APPLICATIONS
- Industrial & commercial power systems
- Data centers, server rooms, ICT infrastructure
- Medical, laboratory & precision instrumentation
- Manufacturing automation and control equipment
- Finance, banking, POS & transaction systems
- Network backbone, broadcast & telecom nodes
Choose our static voltage stabilizer for reliable, efficient, and continuous voltage regulation that protects your equipment and ensures stable operation for your business.
CATALOG
TECHNICAL SPECIFICATIONS
